Forage Maize Harvester

Description

Providing maximum performance with minimum energy consumption is the main characteristic of Challenger® Forage Harvester ROW INDEPENDENT MAIZE CHOPPER offers high harvest with low fuel consumption with its light weight and strong transmission system without exhausting your tractor. Challenger® series is designed in a way that it does not contact with the ground thus keeping the risk of foreign matters getting into the machine at minimum. But we still keep in mind that such a thing can happen, the security is a big part of work at  engineering forage harvester. By doing this, we prevent potential damages from happening.,

Flywheel

Specially designed 12 pieces of flywheel knives are strong against wear and made of high quality materials. Therefore the necessity of frequently replacing knives is prevented. Twelve specially designed
circular knives of the flywheel are made from high quality materials to minimize the necessity of frequently replacing knives.

• In the flywheel system of the machine there are specially designed sweeping paddles. These paddles are sweeping all the silage inside the machine.
• Challenger®’s Forage Harvester ROW INDEPENDENT MAIZE CHOPPER strong blowing system can blow all the silage to the desired area in the trailer with hydraulically controlled funnel and cover.
• One of the most important factors in maize silage is that the maize should be cut and shredded but still remain juicy. Challenger® has the best possible system and equipment to execute this action.

Independent Hydraulic

In addition to being economical, follows the principle of realizing a top class product in terms of the options included in the package. This is why the Challenger is equipped with a fully independent hydraulic system.

Level detection tire

Safety is an important aspect of production! The level tracking sensor, developed by engineers is made
specifically to ensure that the machine is not in the contact with the ground so it minimizes the amount of foreign materials which get into the machine.

Security PIN

All the intake unit is protected by the safety pin. Security pin prevents your machine from getting damaged in case of a soil compaction or foreign materials getting into the machine.

Knife grinding system

The most efficient and accurate silos grinding method. Challenger provides the most efficient and accurate grinding along with their automatic knife sharpening technology.

Intake system

Challenger® 1 brings down tall maize and reduces crop loss to minimum due to row following system. Thanks to its improved flywheel system it makes it easy to reach the highest harvest efficiency possible.

Row Independent MAIZE Chopper Challenger 2

Challenger 2® Row Independent Forage Harvester is designed to harvest maize and various feed plants which are taller than 1 meter disregarding the row thanks to the wide reaping rollers unit. The machine executes its task even in difficult conditions. It does not exhaust your tractor due to its lightweight. You
can be sure that its strong construction will handle pits, bumps and all the other extraordinary conditions.

Corn grain breaking: increase the efficiency of maize silages you make we added corn grain breaking feature to Challenger 2®.

Patented Belt System : Gears in the machine are supposed to take the power they have received from the PTO to make sure the machine is running smoothly. Power transmission through the gears are being done by hoops and belts and thus helping the user with spare parts, maintenance and repair.

Superblow: a system that has been added with fully balanced operation of the sweeping paddles and the inlet of the hydraulic funnel, thereby increasing the blowing force. Also we aimed to provide you with the efficiency that you desired by increasing the blowing capacity and the performance of sweeping paddles.

• Patented Flywheel
• Independent Hydraulic System
• 360 degree Rotating Funnel

OPTIONALS

• 3 Different Ways To Work Challenger 2®  Offers alternative harvest methods alongside with regular ones. This machine has the ability to be mounted in the front, on the sides and at the back of the tractor to harvest. Side and rear standard and front is optional
• 540-750-1000 Rpm Choices The independent two-row forage harvester, adaptable to different
  tractors, offers attachment options to the front, rear and side of the tractor. With transmission RPM options such as 540, 750 and 1000, it enables the most efficient operation.
• Foldable chassis: It is easy, practical and functional to fold and unfold. In addition, the fixing of the machine in the desired position is carried out only with the help of the cover, which prevents loss of time and labor costs.
