Milk cooling tanks vertical
Vertical milk cooling tanks are used to collect and cool milk at dairy farms or milk collection points. The milk cooling tanks designed as a vertical cylindrical container with a built-in compressor & evaporator for cooling. The electronic control unit of the tank maintains the set temperature and the operation of the agitator to prevent the freezing of milk on the walls of the cooling tank. A vertical milk cooling tank is a reliable and easy-to-operate unit within your dairy processing facility.
Vertical Milk cooling tanks
A vertical milk cooling tanks are equipped with a digital temperature display with a phase protection relay. The automatic mixing program controls the operating time of the agitator that can be adjusted as desired intervals (i.e., 3 minutes of mixing operation and 10 minutes stop)
The Refrigeration Unit and the Tanks are completely made of AISI 304 quality food grade stainless steel. The insulation layer polyurethane integral foaming technology, with the international advanced flexible scroll compressor.
The Independent Computer Control System makes the equipment in the intelligent automatic working state. The product has the advantages of fast refrigeration speed, high efficiency, good heat insulation performance, low noise, reliable work, simple operation, long service life, no need for site installation. Ready to work!
The compressor, through the evaporator, condenser with scientific matching, can make milk from 35 degrees to 4 degrees of time in 2 hours Internal and external use of 304 food-grade stainless steel, to ensure food safety.
CIP automatic cleaning is Optional
The optional automatic cleaning (Clean in Place: CIP) device and the electronic metering device. Inner liner clad plate by laser welding, higher strength, no internal leakage, easy to clean, CIP automatic cleaning, cleaning pipeline for 304 stainless steel, no dead angle cleaning CIP automatic cleaning, cleaning pipeline for 304 STAINLESS STEEL no dead corner cleaning.
Milk coolers with manual washing
- Fridge for milk cooling.
- Capacity: from 100 to 2.000 lt.
- Vertical cylindrical tank for milk cooling.
- Internal tank and external coating in stainless steel.
- Millimeter bar in liters for measuring milk.
- Cooling without ice formation even for low filling level.
- Direct expansion.
- Milk temperature control.
- Digital display of milk temperature.
- Programmable stirring.
- Openable lid.
- Manual Washing.
- Single-phase or three-phase power supply.
General description
- Completely made of AISI 304 quality stainless steel
- 1st walla base is 2mm and 0,8 mm Ep type heat transfer plate is coupled to wall
- 1st walla body is 1,5 mm
- Isolation wall is 1mm AISI 304 quality stainless steel
- 1 piece 25 W 25 rpm gearbox and stainless steel agitator coupled with gearbox.
- Agitator special design is to protect milk structure.
- Product Outlet DN 50 male butterfly valve
- Insulation material; HCFC free water based high density polyurethane foam and isolation thickness is 60 mm.
- Spring cover system and Ø 200 mm product inlet.
- Special manual scale with 3-4 ‰ sensitivity rate
- Designed to leave 0 liquid in the tank after discharge
- Tank body coupled on whole chassis
- Argon Tig welding system applied and smoothly polished
- Cooling evaporator (roll bond) is tested up to 40 bar pressure.
- Option: Individual automatic weight measurement with load cell & screen Fridge for milk cooling.
