Description
Ceiling fan
Exceptionally functional and economical Asynchronous gearmotor ceiling fan VS. As barn ventilation fan with axial reducer, gear motor, cost-effective, highly functional and ideal for heavy duty works. Provides high volume air circulation. Fans increase the rate of heat sharing by constantly changing the air near hot systems and increasing molecular collision. Cow Cooling System: For animal cooling should be used together with water spraying. By evaporating moisture on animals, it reduces heat stress and increases comfort. Cow cooling systems are used in barn stalls and milking house parlors.
| Model | KRTUR | MISTRAL | ||||
| Diameter | 4m | 5m | 6m | 4m | 5m | 6m |
| RPM | 110 | 99 | 85 | 98 | 86 | 73 |
| Blade | 5 | 5 | 5 | 6 | 6 | 6 |
| Weight | 94 Kg | 102 Kg | 105 Kg | 61 Kg | 85 Kg | 90 Kg |
| Electric | 380V 3ph | 380V 3ph | 380V 3ph | 380V 3ph | 380V 3ph | 380V 3ph |
| KW | 0,75 | 1,1 | 1,5 | 0,75 | 1,11 | 1 |
| Effective Area Ø | 16 m | 20 m | 24 m | 12m | 14m | 18m |
Influence Area data shown above calculated, according to 4m Installation Height.
Optional fan control units
Main switch: It enables to turn on and off the main energy coming to the box.
Electiric inverter: Depends on number of fans and electrical Kw needs
Speed Controller (Potentiometer): It provides rotating speed control.
Pause / Manual / Automatic modes option switch: Provides to select either Pause or Manual or Automatic modes. If system equipped with temperature sensor, there is automatic mode option on the control panel.
Ceiling fan is
In addition to being quieter and more economical than horizontal fans, it meets high efficiency expectations with efficiency, low power consumption and low maintenance costs. Due to the advantages, it provides, its use has been more effective, beneficial and economical. It offers ideal solutions as a ventilation fan for industrial areas, warehouses and industrial facilities as well as for dairy and fattening barns.
Climates with high humidity where ground and air drying are important (soil / compost floors), for curtained or open-sided or semi-open barns with natural ventilation, creating a high enough air speed; It dries the floor and creates a cold wind effect on animals.
